LT1306-A
1275PSI High Performance Steel Reinforced Concrete Pumping Hose
Application:Reinforced concrete pump hose, special easy to operate design, suitable for concrete pouring site

Inner Tube:Black NR conductive rubber-abrasion resistant
Reinforcement:High tensile steel cords
Outer Layer:Black SBR/NR blend conductive rubber, abrasion-resistant, oxidation-resistant
Working Pressure:85Bar(1275PSI)
Temperature Range:-30℃(-22°F)~+80℃(+176°F)
1275PSI High Performance Steel Reinforced Concrete Pumping Hose
Parameter
Specifications
Series ID(in.) ID(mm) OD(in.) OD(mm) Wall Thickness(mm) MaxRec.WP(PSI) Min.B.R Weight(kg/m)
LT1306-200 2 51 2.72 69 9 1275 10 2.14
LT1306-250 21/2 63 3.35 85 11 1275 101/2 3.35
LT1306-300 3 76 3.94 100 12 1275 15 4.55
LT1306-400 4 102 5.04 128 13 1275 20 7.02
LT1306-500 5 127 6.10 155 14 1275 25 10.34


Note: The actual parameters are subject to the final atlas
