Long Life Solution For Excavator Hydraulic Lines

Letone provides hoses, assemblies, crimping parameters, technical services, and quality assurance. The assemblies have a one-year warranty, while Letone Technology provides crimping services with a two-year warranty.

Inner rubber layer: Nitrile/chloroprene synthetic rubber, suitable for biodegradable hydraulic oils.
Reinforcing layer: One layer of steel wire braid (1/2" – 3/4"), impulse ≥ 300,000 times; Four layers of steel wire winding (1" – 2"), impulse ≥ 1 million times.
Outer rubber layer: Standard tube: peel-free, wear-resistant, and weather-resistant synthetic rubber; Wear-resistant tube: peel-free, high wear-resistant, and weather-resistant synthetic rubber; Ultra-wear-resistant tube: peel-free, ultra-wear-resistant, and weather-resistant UHMWPE.
Temperature range: -40℃ to +121℃ (-40℉ to +250℉).
Implementation standard: Exceeds ISO18752-AC/CC standard.
Bending radius: 41% less than ISO 18752 standard; 47% less than SAE standard; pressure exceeds SAE standard by 60%.

Product Advantages

Letone's Super Artery long-life excavator hoses have a bending radius 34% lower than the ISO18752 Class C standard, and each hose has over 1 million impulse cycles. When used with Letone Technology's self-developed hose connectors and hydrogenated nitrile butadiene seals, the service life can exceed 5 years (with a 2-year warranty). We strive to provide a "time-saving, labor-saving, hassle-free, cost-saving, and worry-free" service.

Softness

Low-temperature bending performance: under -40°C testing conditions, the bending radius is reduced by 50% compared to the DIN EN853 standard; the bending radius of the 1” 42MPa Super Artery low-bending series hose is approximately 250mm.
Impulse performance

Tested with impulses at 1.33 times the working pressure, performance exceeds 1 million impulse cycles.
abrasion resistance

The wear of the ultra-wear-resistant outer layer was 0g under experimental conditions.
Explosive

4 times the work pressure





Super Artery Long Life Series Hose Comparison With Standard

Super Artery long-life series hoses are high-end products in the hydraulic piping field. Their main performance indicators are comparable to those of well-known international brands, as shown in the following comparison:

Product performance (taking 1/2” as an example)	DIN standard / GB / T3683 / SAE J517 100R2	ISO18752- 2BC	Letone Technology Super Artery Low Bending Series LTSA5992
Work pressure（MPa）	27.5	28	35
Number of impulses (in ten thousand times)	20	50	100
Bending radius（mm）	180	144	90
Operating temperature（℃）(Upper limit)	100	100	121
Operating temperature (°C) (lower limit)	-40	-40	-40
Corrosion resistant (IRM903 oil, shrinkage rate %)	0-25	0-25	0-10
Resistant to aging (ozone, h)	72	72	1000

Honors And Qualifications

For many years, Letone has consistently adhered to the core values of "integrity first, customer foremost" and steadfastly promoted the development strategy of "innovation-led, talent cultivation as a priority, rooted in excellence, and striving for the pinnacle." The company focuses on the upstream and downstream industrial chains of rubber hoses, conducting technological research and development and manufacturing of polymer materials, hydraulic hoses, industrial hoses, oil drilling hoses, food and pharmaceutical hoses, rubber seals, and fluid connectors.
