Super Artery Hose

Suitable for excavators and other types of engineering machinery, construction machinery, mining machinery, and agricultural machinery. Capable of conveying water-based, petroleum-based, and biodegradable hydraulic oils in harsh working environments.

Inner adhesive layer：Nitrile/chloroprene synthetic rubber, suitable for biodegradable hydraulic fluids.
Reinforcement：One layer of steel wire braid (1/2" – 3/4"), impulse ≥ 300,000 times; four layers of steel wire winding (1" – 2"), impulse ≥ 1,000,000 times.
Outer adhesive layer：Standard pipe: peel-free, wear-resistant, and weather-resistant synthetic rubber; Wear-resistant pipe: peel-free, high wear-resistant, and weather-resistant synthetic rubber; Ultra-wear-resistant pipe: peel-free, ultra-wear-resistant, and weather-resistant UHMWPE.
Temperature range：-40℃~+121℃（-40℉~+250℉）。
Implementation Standards：It exceeds the ISO18752-AC/CC standard.
Bending radius：It reduces pressure by 41% compared to the ISO 18752 standard; it reduces pressure by 47% compared to the SAE standard; and it exceeds the SAE standard by 60%.

Product Advantages

Super Artery hose features low bending, high pressure, and long lifespan (using Letone's exclusive one-piece hose fittings, weather-resistant for over 5 years, with a 2-year warranty). It has been tested under industry-leading conditions of one million impulse cycles (weather-resistant for over three years), and its bending radius is 30% lower than the SAE/DIN standard.

Softness

Low-temperature bending performance: under -40°C testing conditions, the bending radius is reduced by 50% compared to the DIN EN853 standard; the bending radius of the 1” 42MPa Super Artery low-bending series hose is approximately 250mm.
Impulse performance

Tested with impulses at 1.33 times the working pressure, performance exceeds 1 million impulse cycles.
abrasion resistance

The wear of the ultra-wear-resistant outer layer was 0g under experimental conditions.
Explosive

4 times the work pressure





Frequently Asked Questions

Use and maintenance of rubber hoses

(I) Select the correct type and size of hose according to the usage conditions to prevent misuse and substitution. It is strictly forbidden to use low-pressure hoses instead of high-pressure hoses, or to use ordinary (air or water) hoses instead of special hoses for conveying corrosive media such as acids (alkalis) or oils.
(II) For hoses conveying acids (alkalis), oils, etc., the medium inside the hose should be drained after each use, and the hose should be cleaned promptly to prevent residue from corroding the hose body.
(III) Hose used seasonally must be cleaned and properly stored after use.

Super Artery Series Hoses Compared To Standard Hoses

Letone Artery and Super Artery hoses feature low bending, high pressure, and long lifespan (using Letone's proprietary integrated hose fittings, weather-resistant for over 5 years, with a 2-year warranty). They have been tested under industry-leading conditions of one million impulse cycles (weather-resistant for over three years), and their bending radius is 30% lower than the SAE/DIN standard.。

Application Scope

Letone Artery & Super Artery hoses are suitable for conveying water-based, petroleum-based, and biodegradable hydraulic oils in harsh working environments, such as excavators, construction machinery, mining machinery, and agricultural machinery.

Honors And Qualifications

For many years, Letone has consistently adhered to the core values of "integrity first, customer foremost" and steadfastly promoted the development strategy of "innovation-led, talent cultivation as a priority, rooted in excellence, and striving for the pinnacle." The company focuses on the upstream and downstream industrial chains of rubber hoses, conducting technological research and development and manufacturing of polymer materials, hydraulic hoses, industrial hoses, oil drilling hoses, food and pharmaceutical hoses, rubber seals, and fluid connectors.
